TORQUE RESISTANT BUSHING KBDR1-50-WV-K

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TORQUE RESIST.BUSH KBDR1-50-WV-K (R069605089) is a highly specialized component designed for self-supporting, torsionally stiff guides that require only one shaft. This torque-resistant linear bushing is standard equipment without a seal and includes a precision steel shaft that is machined to customer specifications. The shaft diameter 'd' is accompanied by ball guide grooves that enable the transfer of torques with high precision. The KBDR1-50-WV-K model boasts a robust construction with ball retainers and an outer sleeve made of either PA or POM, ensuring durability and consistent performance. The hardened steel bearing plates, along with balls made of rolling bearing steel, contribute to the component's reliability and longevity. An adjusting screw made from hardened steel allows for zero-clearance settings, while the steel lock nut ensures secure positioning. This linear bushing and shaft system are ideal for applications requiring precise linear movement combined with the ability to withstand torsional forces. The dynamic torsional moment load capacity Mt and dynamic load capacity C are indicative of its ability to handle significant loads, although these capacities are minimal values due to potential variations in loading directions. With a permissible ambient temperature range from -20°C to +80°C, the KBDR1-50-WV-K can operate effectively in various environments. Its design facilitates maximum acceleration and permissible linear speed while maintaining stability. The outer diameter 'D' caters to specific application requirements, and despite its robustness, the unit maintains an efficient weight-to-performance ratio. Overall, this Bosch Rexroth torque-resistant linear bushing is an essential component for applications demanding high precision linear guidance coupled with torque resistance capabilities.
