SUPER LINEAR BUSHING KBB-O-40-VD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SUPER LINEAR BUSH KBB-O-40-VD (R067324045) is a precision-engineered linear bushing designed to provide smooth and accurate linear motion in various applications. This model is characterized by its open design and fully sealed features, ensuring protection against contaminants while maintaining high travel speeds of up to 5 meters per second. The KBB-O-40-VD does not have a self-alignment feature, which means it is capable of transferring lower tipping forces along the axial direction, making it suitable for use on fully supported shafts where other linear guides may experience warping due to imprecise substructures. Constructed with steel bearing plates that have machined ball guide grooves and optimized ball lead-in chamfers, this bushing promises exceptionally smooth travel and a long service life. The design includes integrated wiper seals that contribute to the unit's low maintenance by preventing the ingress of dirt and debris. The ball retainer and outer sleeve are made from either PA or POM materials, while the balls themselves are crafted from rolling bearing steel, ensuring durability and consistent performance. The SUPER LINEAR BUSH has a maximum dynamic load capacity (C) indicating its ability to withstand forces during motion, complemented by a static load rating (C0) for when the bushing is stationary. It operates efficiently within an ambient temperature range of -10°C to +100°C. Its size E designation corresponds to an outer diameter D of 62 mm, while the breakaway force required for movement is minimal due to its sophisticated design. This product has a weight of 0.4 kilograms and comes with various radial clearance options for different applications. With no initial lubrication required upon installation, this Bosch Rexroth linear bushing is ready for immediate use in systems requiring precise linear guidance with minimal frictional drag and maintenance needs. Productgroup ID indicates its categorization within Bosch Rexroth's product offerings as a high-quality linear guide component suitable for diverse industrial applications.
