SUPER LINEAR BUSHING KBB-O-25

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SUPER LINEAR BUSH (R067302500) is a high-quality linear bushing designed for precise linear motion applications. This model, part of the Super LB B series, is characterized by its open design without a seal, which makes it suitable for fully supported shafts where other linear guides may fail due to warping from imprecise substructures. The SUPER LINEAR BUSH is crafted with steel bearing plates that feature machined ball guide grooves and optimized ball lead-in chamfers, ensuring smooth travel and a long service life. The bushing has no self-alignment feature, which means it can transfer lower tipping forces along the axial direction. It boasts a high travel speed capability and can handle maximum accelerations effectively. The product is engineered with ball retainers and an outer sleeve made of either PA or POM materials, while the balls themselves are constructed from rolling bearing steel. This model does not require initial lubrication, which simplifies installation and maintenance. Capable of operating within an ambient temperature range of -30°C to +80°C, the SUPER LINEAR BUSH maintains its performance in various environments. With a dynamic load capacity C and static load rating C0 that apply to the main direction of loading, this bushing ensures reliable operation under various load conditions. It has been tested for total travel from 100 km to 50 km without failure, highlighting its durability. The SUPER LINEAR BUSH features a low friction coefficient that varies depending on load conditions but remains efficient under both heavy and light loads when lubricated with oil. The product's weight is minimal at 0.2 kg, contributing to its ease of integration into various systems without adding significant mass. Overall, the Bosch Rexroth SUPER LINEAR BUSH (R067302500) provides robust performance for applications requiring precise linear motion control with high requirements for smoothness and longevity in operation.
