LIFT POSITIONING UNIT HP 2
Manufacturer: Bosch Rexroth
Material #: 3842999678
Model : LIFT POSITION UNIT HP 2
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LIFT POSITION UNIT HP 2 (3842999678) is a sophisticated pneumatic lifting module designed for precise positioning and handling of workpiece pallets within automated systems. This unit excels in applications where repeatable accuracy and controlled motion are paramount. With its ability to provide infinitely adjustable lift heights in two ranges, hN and hsubNsub, it can accommodate a variety of tasks.
The HP 2 lift positioning unit features a lifting cylinder with adjustable damping at both the upper and lower end positions, ensuring smooth operation and reduced impact at the endpoints of the lift cycle. Notably, the upper end damping is only activated when there is a full lift, which helps to preserve the integrity of the mechanism over time.
It is engineered for compatibility with Bosch Rexroth's WT series workpiece pallets, including models WT, WTF, and WTE. This compatibility allows for seamless integration into existing conveyor systems or for setting up new production lines with minimal hassle. The unit boasts an impressive repetition accuracy and can handle permissible vertical process forces effectively.
Moreover, the HP 2 unit supports ESD-sensitive applications thanks to its electrostatic discharge capabilities. It comes fully assembled with all necessary fastening materials and includes a switch bracket for mounting M sensors that enable top and bottom lift position inquiries.
This model has been designed with user convenience in mind; it requires minimal additional accessories—only a stop gate VE..., throttle non-return valve, exhaust air G1/4 with diameter 4 mm sensor—and offers preferred lengths in direction of transport lT options to cater to various system requirements. The maximum load version Fmax ensures that it can handle significant weights safely while maintaining precision.
In summary, the Bosch Rexroth LIFT POSITION UNIT HP 2 (3842999678) stands out as an essential component for any high-precision assembly line or material handling system that requires exact positioning combined with smooth and controlled lifting capabilities.
This product is not available. CLICK HERE to create a support ticket for us to locate your part or a suitable replacement
