POSITIONING UNIT PE 2/X

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth POSITIONING UNIT PE 2/X (3842998324) is a precision-engineered component designed to accurately position workpiece pallets within manual or automatic processing stations. This unit boasts a positioning accuracy of up to 0.1 mm when installed on a separate machine frame, ensuring high precision for intricate tasks. The unit facilitates a lift of the workpiece pallet above the transportation level by approximately 85 mm, allowing for seamless operation during the manufacturing process. Equipped with positioning pins of the PE 2 and bushings of the WT workpiece pallet, it ensures secure and precise placement. The PE 2/X is also versatile in its installation options, featuring mounting bores on the lift frame that can serve as fastening points for an independent machine frame if required. It is designed to be compatible with ST sections having profile widths of either 45 mm or ST H sections with profile widths of 90 mm, providing flexibility in terms of system integration. The unit can be combined effectively with WT and WTF workpiece pallets, making it a versatile addition to various conveyor systems. It has been constructed keeping in mind repeatable accuracy and can handle a permissible vertical process force effectively. Additionally, the PE 2/X supports ESD requirements and includes pneumatic straight connections for necessary compressed air connections ranging from pmax to pmin. This positioning unit comes fully assembled and includes essential fastening material, along with a switch bracket designed for mounting M sensors that facilitate position inquiry from above. The scope of delivery ensures that all components required for immediate operation are included upon purchase. With its robust construction and precise functionality, the Bosch Rexroth POSITIONING UNIT PE 2/X (3842998324) is an integral component for any automated system requiring reliable and accurate positioning capabilities.
