3842538308

CARRYING PLATE 480X400X12,7 ALU

Manufacturer: Bosch Rexroth

Material #: 3842538308

Model : CARRYING PLATE 480X400X12,7 ALU

$360.92 USD

More are expected on July 18, 2024

Add to Cart

Status: This product is temporarily out of stock.

Qty: Delivered as early as July 18, 2024 when ordered in

CARRYING PLATE 480X400X12,7 ALU

Carrying plate WT 2, AL 12.7 400/480

Unpacked Weight: 6.4 kg

For self-assembly of workpiece pallets for product support
Completely drilled and ready for assembly
15 standard sizes in steel, 4.8 mm thick, with KTL (cataphoretic primer) coating
10 standard sizes in aluminum, 8 mm thick
13 standard sizes in aluminum, 12.7 mm thick
You will find drilling plans for identification and data storage systems in the RFID systems catalog
Can be combined with frame modules of WT 2 workpiece pallets

Data Sheet	Download Data Sheet
3D CAD	Download 3D CAD

Plate thickness [dPL]	12.7
Productgroup ID	2
Workpiece pallet total weight [mG]	100
Dimension [a]	108.5
Flatness	0.6
Material	Aluminum
Weight	6.4
Notice	with four threaded holes for reinforcing bolts
Workpiece pallet width [bWT]	400
Workpiece pallet length [lWT]	480
