WORKPIECE PALLET LWT240 BWT240

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth WORKPIECE PALLET LWT240 BWT240 (Material Number 0842090039) is a high-rigidity workpiece pallet designed for use in conveyor systems such as the TS 2plus transfer system. This fully assembled pallet measures 240x240 mm and is constructed from a robust plastic frame module made of polyamide (PA) with a wear pad, coupled with a universal steel carrying plate that is 4.8 mm thick. The design of the WT 2 workpiece pallet incorporates integrated positioning bushings and is prepped for the installation of mobile data tags compatible with the ID 15, ID 40, and ID 200 identification systems. This particular model of workpiece pallet is not suitable for use with accumulation roller chains but is tailored for belt, toothed belt, and flat top chain conveyance applications. Its construction allows for reliable support and transportation of various workpieces within automated systems. The product's material composition ensures durability and suitability for various industrial environments, including Electrostatic Protected Areas (EPA). The WT 2 series offers fifteen standard sizes to accommodate different requirements, and from size 400 x 400 mm upwards, additional threaded holes are provided for reinforcing bolts as per standard specifications. This feature enhances the structural integrity of larger pallets when used in demanding applications.
