VT-VACAP-500-20/V0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth VT-VACAP-500-20/V0 (0811405157) is an advanced analog amplifier designed for controlling high-response valves equipped with integrated electronics. It features a sophisticated amplifier module complemented by an additional electronics daughter card, ensuring precise and efficient operation. This model is specifically formatted for installation in standard 19" European racks, making it suitable for a wide range of industrial applications. The device boasts valve position control capabilities with PID behavior, which allows for meticulous control over the valve's operation, ensuring accuracy and stability in the system's performance. The outputs of the VT-VACAP-500-20/V0 are short-circuit-proof, enhancing the safety and reliability of the system. An important feature of this amplifier is its external shut-off functionality for the pressure controller, providing an additional layer of control and safety. It is compatible with a variety of pressure sensors as indicated by data sheet 30271, including those with outputs ranging from 1 to 6 V, 0 to 10 V, and 4 to 20 mA. Furthermore, this model includes a supply for pressure sensors and has a built-in cable break detection feature for the pressure sensor. This ensures that any disruption or fault in the sensor's connectivity is promptly detected, preventing potential system failures or inaccuracies. In summary, the Bosch VT-VACAP-500-20/V0 (0811405157) is a robust and precise analog amplifier suitable for controlling high-response valves with installed electronics. Its design accommodates various sensor types and includes features that ensure safety and reliability in demanding industrial environments.
