4WRPEH10C5B100P-2X/G24K0/A1M

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WRPEH10C5B100P-2X/G24K0/A1M (0811404827) is a high-response directional valve designed for precise control in electro-hydraulic systems. It is a direct-operated valve with a control spool and sleeve in servo quality, ensuring reliable and accurate operation. The valve features integrated electronics that compare the specified command value with the position actual value to adjust the stroke solenoid accordingly, modulating the control spool against the spring based on control deviations. This model includes an electric position feedback mechanism and factory-calibrated integrated electronics (OBE), which contribute to its precise functioning. The electrical connection is a 6P+PE type, and it accepts signal input through either an "A1" interface with ±10 V or an "F1" interface for 4 ... 20 mA signals (with Rsh = 200 Ω). Its design facilitates use in production and test systems that require electro-hydraulic controls. The valve operates on one side and ensures a 4/4 fail-safe position when switched off, immediately moving to a secured basic position for safety. This switch-off behavior includes passing through positions P–B/A–T, which may cause movements in the controlled component and should be considered during system design. The product consists of three main components: the control solenoid with a position transducer, the valve body, and the mating connector. This Bosch directional valve is suitable for applications requiring precise movement control and quick response times, such as in advanced manufacturing processes or testing environments where hydraulic controls are integral to operations. It offers reliability through its direct operation mechanism and safety through its fail-safe positioning feature.
