0811404822

4WRPEH10C3B50P-2X/G24K0/A1M

Manufacturer: Bosch Rexroth

Material #: 0811404822

Model : 4WRPEH10C3B50P-2X/G24K0/A1M


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WRPEH10C3B50P-2X/G24K0/A1M (0811404822) is a high-response directional valve characterized by its precise operation and reliability. This direct-operated valve integrates a control spool and sleeve of servo quality, ensuring accurate control for electro-hydraulic systems. It is designed with a 4/4 fail-safe position that guarantees the valve shifts to a secure basic position when electronics are switched off, which is critical for system safety. Equipped with an electric position feedback and integrated electronics (OBE), the valve is factory-calibrated for immediate use. The electrical connection is a 6P+PE type, and it features a differential amplifier signal input interface "A1" which accepts ±10 V or an "F1" interface for a 4 to 20 mA signal with Rsh = 200 Ω. These interfaces allow for flexible integration into various control circuits. The design includes a control solenoid with a position transducer that ensures proportional stroke/control cross-section adjustment in response to the command value. This precision allows for fine-tuning of hydraulic flows necessary in sophisticated production and test systems. The spring-centered control spool automatically adjusts to the central position at a command value presetting of 0 V, providing stability in neutral conditions. The switch-off behavior of this valve ensures immediate transition to fail-safe positions upon power loss, moving through P–B/A–T positions which may influence movements at the controlled component—a factor that must be considered during system design. This Bosch valve is ideal for use in electro-hydraulic controls within production environments and testing setups where precise fluid control is essential. Its robust construction and reliable operation make it suitable for demanding applications requiring accurate hydraulic flow regulation.

This product is not available. CLICK HERE to create a support ticket for us to locate your part or a suitable replacement

This product is eligible for factory repair.
