4WRPEH10C1B100L-2X/G24K0/A1M

Manufacturer: Bosch Rexroth

Material #: 0811404821

Model : 4WRPEH10C1B100L-2X/G24K0/A1M


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WRPEH10C1B100L-2X/G24K0/A1M (0811404821) is a high-response directional valve, crafted for precision in electro-hydraulic control systems. It is direct operated with a control spool and sleeve of servo quality, ensuring responsive and accurate performance. This model features an integrated electronics system that compares the command value to the actual position value, activating the stroke solenoid to adjust the control spool against the spring for proportional control of the stroke/control cross-section. This valve is designed with a unique fail-safe mechanism; in its deactivated state, the spring is fully untensioned, allowing the valve to revert to a secure basic position. This switch-off behavior ensures immediate movement into this fail-safe position when electronics are turned off, passing through P–B/A–T positions which could result in movements of controlled components—this should be factored into system design considerations. The 4WRPEH10C1B100L-2X/G24K0/A1M comes equipped with an electric position feedback system and factory-calibrated integrated electronics (OBE), enhancing its reliability and ease of use. The electrical connection is facilitated through a 6P+PE connector, while signal input can be managed via a differential amplifier with an "A1" interface at ±10 V or an "F1" interface for 4 ... 20 mA signals (with Rsh = 200 Ω). This Bosch valve is ideally suited for application in production and test systems where precise electro-hydraulic controls are required. Its robust construction and advanced electronic integration make it a reliable component for sophisticated hydraulic applications demanding high accuracy and repeatability.

This product is not available. CLICK HERE to create a support ticket for us to locate your part or a suitable replacement

This product is eligible for factory repair.
