4-WAY DIRECT OPERATED D03 (NG6) DIRECTIONAL CONTROL VALVE, WITHOUT ELECTRONICS

Material #: 0811404036

Model : 4WRPH 6 C3 B40L-2X/G24Z4/M

Price: $4,383.00

4-Way Direct Operated D03 (NG6) directional control valve, without electronics
4WRPH6 are high performance, proportional directional control valves with precision sleeve and spool assembly with zero overlap. The 4th position spool is spring offset to a failsafe during power lose or fault. The dynamic servo-solenoid has electrical position feedback that requires external amplifier. These are widely used control valves for demanding, closed loop applications.

Buy Now

$4,383.00

In Stock: 19
Available for immediate shipment

Need more? We have you covered! Place your order today and we will ship when more are expected on February 2, 2024
Material0811404036
AccessoriesR900011039
Shipping height115 mm
Shipping length198 mm
Shipping weight estimated2.8 kg
Shipping width46 mm
Datasheet nameRE29028
Connector position feedback4-pole (small cubic connector)
Connector solenoidappliance inlet 3-pol (2 + PE&
Flow characteristicLinear
Model Code4WRPH 6 C3 B40L-2X/G24Z4/M
Rated flow valve pressure differential p 70 bar40 l/min
Seal materialNBR seals
Series2X
Size6
Special Version-
SymbolsC3
