Manufacturer: Bosch Rexroth

Material #: 0811403577

Model : 4WRPNH6C4B15P-2X/M/24PA6C-561

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WRPNH6C4B15P-2X/M/24PA6C-561 (0811403577) is a state-of-the-art high-response valve integrated with an axis controller, designed for precision flow, position, and pressure control in various applications. This direct-operated valve features a control spool and sleeve of servo quality, ensuring reliable performance in demanding environments. The integrated digital axis controller (IAC-R) provides functionalities such as flow control, position control, pressure control, p/Q function, and substitutional position/pressure or position/force control with NC functionality. The valve allows command value presetting through either an analog interface or a field bus interface, while actual value signals are available via analog and can also be accessed through the field bus. Controller parameters are settable via the field bus for ease of customization. A separate supply voltage is designated for the bus/controller and power part to enhance safety measures. For project planning and parameterization tasks, Bosch offers the WinHPT commissioning software compatible with Windows 2000 or XP. This software facilitates parameter setting, programming of NC functionality, diagnostics, and data management on a PC. The IAC-R valve's integrated electronics support error detection capabilities such as cable break sensor technology checks, undervoltage monitoring, temperature checks of the electronics, communication error identification, and watchdog functions. Additional features include ramp generator support, internal command value profile creation, enable function in both analog/digital forms, error output signaling up to 24V at a maximum of 1.8A current for interfacing with PLCs or logic systems. This versatile valve is equipped with functionalities like actuating variable adaptation; dead band compensation; zero point correction; valve inflection compensation; friction compensation; direction-dependent amplification; and offers multiple interface options including CAN bus with CANopen protocol DS408 and Profibus-DP Vo/V1. Quick start-up is facilitated through PC-based commissioning software which simplifies initial setup procedures.

This product is not available. CLICK HERE to create a support ticket for us to locate your part or a suitable replacement

This product is eligible for factory repair.
