4WRPNH 10 C4 B100L-2X/M/24PA6A

Manufacturer: Bosch Rexroth

Material #: 0811403366

Model : 4WRPNH 10 C4 B100L-2X/M/24PA6A

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WRPNH 10 C4 B100L-2X/M/24PA6A (0811403366) is a state-of-the-art high-response valve equipped with an integrated digital axis controller (IAC-R), designed for precise flow, position, and pressure control. This advanced component offers users the ability to perform substitutional position/pressure or position/force control with NC functionality. The valve features multiple interface options, including analog interfaces (X1, X4, X7) for command value presetting and actual value signals, as well as a field bus interface (X3) for setting controller parameters and reading out actual values. The IAC-R valve is notable for its direct operation with a control spool and sleeve of servo quality, ensuring high precision in performance. The integrated axis controller facilitates sophisticated operations such as ramp generation, internal command value profiling, and various compensations such as dead band, zero point correction, and friction compensation. It also includes safety features like separate supply voltage for the bus/controller and output stage. Moreover, the valve's digital electronics support error detection capabilities like sensor cable break monitoring, undervoltage detection, temperature monitoring of the electronics, communication errors check, and watchdog functionality. Additional features include an enable function in both analog and digital forms, error output at 24 V with a maximum of 1.8 A capacity for interfacing with PLCs or additional valves. For commissioning and diagnostics purposes, Bosch provides WinHPT PC software compatible with Windows 2000 or XP operating systems. This software assists users in parameterization tasks and programming of NC functionalities while offering user-friendly data management. In terms of connectivity options for this high-response valve with integrated axis controller feature CAN bus with CANopen protocol DS408 and Profibus-DP Vo/V1 protocols for fieldbus connections. It supports quick start-up procedures through PC-based commissioning software to streamline setup processes.

This product is not available. CLICK HERE to create a support ticket for us to locate your part or a suitable replacement

This product is eligible for factory repair.
