4WE 10 E4X/CW110N9DAL/V=CSA

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE 10 E4X/CW110N9DAL/V=CSA (R900618756) is a high-performance directional spool valve designed to control the start, stop, and direction of fluid flow within a hydraulic system. This model features a housing, one or two wet-pin electronic solenoids, a control spool, and return springs. The solenoids actuate the control spool, which directs the flow from P to A and B to T or P to B and A to T. When not energized, the return spring returns the control spool to its neutral position. The valve includes a manual override feature enabling manual operation without solenoid power. It is important that the pressure chamber of the solenoid is filled with oil for proper function. The model also offers optional throttle inserts for channels P, A, B, or T to manage flow resistance under specific operating conditions. This particular version of the valve does not have spring return at the control spool; thus it doesn't default to a set position when de-energized unless it's in version OF with detents that lock the control spool in place for energy-efficient operation. However, if multiple valves share a tank line, pressure peaks may cause unintended movements of the control spool; therefore separate return lines or check valves are recommended. The 4WE 10 E4X/CW110N9DAL/V=CSA valve has several configurations available: with or without detents and with various numbers of spool positions and electronic solenoids. The high-power solenoid ensures reliable operation while porting patterns are in accordance with ISO standards. Solenoid coils can be rotated by 90 degrees and replaced without opening the pressure-tight chamber for maintenance ease. Electrical connections can be made individually or through central connections with an optional auxiliary operating device available for increased versatility in application.
