HOLLOW SHAFT WO-50H7-CR

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth HOLLOW SHAFT WO-50H7-CR (R100105041) is a precision-engineered component designed for use in linear motion applications requiring high-quality motion control and durability. This tubular shaft, which is part of the Hohlwelle Series, is crafted from heat-treated steel and features a hard chrome plating that provides optimal surface corrosion protection. The chrome plating also imparts a hardness of approximately HV 850-1000 with a chrome plating thickness of around 10-30 µm, ensuring long-term performance under demanding conditions. With its precise manufacturing, the shaft diameter adheres to an H7 tolerance grade, ensuring compatibility with linear bushings designed for high precision and smooth movement. The surface roughness of RA 0.2-0.4 µm facilitates reduced friction and extended life for components that move along the shaft. Its cylindricity and roundness tolerances are meticulously controlled to ensure consistent performance and reliability. The WO-50H7-CR shaft supports a maximum usable length (Lmax), providing flexibility in application design while maintaining straightness within tight tolerances as per ISO standards. The straightness tolerance ensures that the smallest possible deviation is only 0.5 m for lengths under 1 meter, which speaks to the exceptional quality control in its manufacturing process. This model's mass is approximately 9 kg/m, making it suitable for various industrial applications where weight considerations are essential without compromising structural integrity or performance. Overall, the Bosch Rexroth HOLLOW SHAFT WO-50H7-CR represents a top-tier option for designers seeking robust and precise components for their linear motion systems.
