PR12-36B-0-N-04/02 REDUCING VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5616915.02 (5616915.02) is a spool type, pilot operated hydraulic pressure reducing/relieving valve designed to regulate pressure in secondary circuits. This model features an internal pilot and an internal spring chamber drain, allowing it to efficiently manage hydraulic flow and pressure. In its steady state, the PR12-36X valve permits bidirectional flow from port 2 to port 1 while continuously draining the spring chamber at port 3. When a predetermined pressure is reached at port 1, the spool shifts to limit the inlet flow from port 2, effectively regulating the pressure at port 1. Additionally, in this mode, it can relieve excess pressure from port 1 to port 3. It is important to note that tank pressure contributes to the overall regulated pressure. The valve's design includes adjustments that cannot be backed out of the valve and ensures that springs do not go solid during operation. Furthermore, it offers optional spring ranges up to 207 bar (3000 psi), providing flexibility for various applications requiring precise hydraulic control and safety under high-pressure conditions.
