RV10-28A-8T-N-07/02 RELIEF VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5613708.02 (5613708.02) is a screw-in, cartridge-style, pilot-operated relief valve with an integrated reverse free flow check valve. This versatile component is designed to serve as a pressure-limiting device in demanding hydraulic circuits that require fast response times, low hysteresis, minimal leakage, and low pressure override capabilities. The RV10-28X model effectively blocks flow from port 1 to port 2 until a preset pressure level is reached at port 1, at which point the relief flow path opens from port 1 to port 2. Additionally, it allows reverse flow from port 2 to port 1 when the pressure at port 2 exceeds that at port 1. The valve offers a variety of adjustment options that cannot be backed out once set, ensuring reliable operation in both relief valve and check valve modes. It also supports several pressure ranges and features a hardened spool and cage for enhanced durability and long service life. With its industry-common size, the RV10-28X can be seamlessly integrated into various applications requiring precise control over hydraulic pressure and flow direction.
