RV10-20H-8T-N-23/18 RELIEF VALVE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5610467.18 (Material Number: 5610467.18) is a screw-in, cartridge-style, direct-acting poppet type hydraulic relief valve designed for pressure limiting in hydraulic circuit protection. This valve is compatible with both mineral-based and synthetic hydraulic fluids that possess lubricating properties. The RV10-20X model efficiently blocks flow from port 1 to port 2 until the pressure at port 1 is sufficient to unseat the poppet, thus ensuring rapid response to load changes in typical hydraulic systems while maintaining low internal leakage. It serves as a reliable component for existing and new applications, although users are encouraged to consider the RVD58-20 as a more advanced alternative due to its superior performance characteristics such as comparable pressure and flow ratings, better pressure rise characteristics, smaller size, and competitive cost. However, it should be noted that the GRV10-20 corrosion-resistant version of this valve is not recommended for crossover applications.
