AXIAL-PISTON MOTOR A2FM80/61W-VAB010 GO2EU

Manufacturer: Bosch Rexroth

Material #: R902230040

Model : A2FM80/61W-VAB010 GO2EU

Destination

$5,568.07 USD

Availability: Backordered

Ships from CA

Add to Cart

Note: Sales tax, shipping, and applicable tariffs will be calculated at checkout.

Qty:
Delivered as early as December 22, 2026

AXIAL-PISTON MOTOR A2FM80/61W-VAB010 *GO2EU*

A2FM, fixed displacement unit, closed circuit, high pressure, size: 80 cm³

A2FM is a fixed displacement motor with an axial tapered piston rotary group in bent axis design for hydrostatic drives in the open and closed circuit. With axial piston units in bent axis design, the pistons are arranged at an angle to the drive shaft. The pistons rest directly on the drive shaft where they generate torque depending on the pressure.

Unpacked Weight: 28 kg

Data Sheet	Download Data Sheet
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual

Product family	A2FM
Product (axial piston unit)	A2FM
Type of actuation	Motor
Size (displacement)	80
Series	61
Direction of rotation	alternating
Sealing material	FKM
Low temperature version	no
Shaft end	A (splined shaft DIN 5480)
Mounting flange	4-hole ISO 3019-2
Working ports	01 (port A, B;SAE rear)
Speed sensing	without
Pressure relief valve	without
Rotary group, hydraulic part	Standard
Drive shaft bearing	Standard bearing
Shaft seal	Standard WDR
Housing ports	Leakage oil port T1
Housing port, status	Leakage oil port T1 plugged
Installation version of port plate	Installation version 1 (standard)
Mounting bolts	Standard
Port plate	A-Standard
Max. flow	0.0
Classification society (external)	Standard (without acceptance)
Test certificate	without
Test certificate language code	Without
Paint/base coat	RAL 9005 deep black
Paint/top coat	without
Productgroup ID	9,10,11,12,13,14
Weight	28
