PROPORTIONAL DIRECTIONAL VALVE 4WRLE10V100P-4X/MXT/24F1

Manufacturer: Bosch Rexroth

Material #: R901475914

Model : 4WRLE10V100P-4X/MXT/24F1

Destination

$10,612.56 USD

Availability: Backordered

Ships from CA

Add to Cart

Note: Sales tax, shipping, and applicable tariffs will be calculated at checkout.

Qty:
Delivered as early as February 16, 2027

PROPORTIONAL DIRECTIONAL VALVE 4WRLE10V100P-4X/MXT/24F1

Size 10, symbol V, electrical with integrated electronics, 24 V DC

Industrial hydraulic valve in the high performance range; reliable control of the oil flow direction according to the hydraulic symbol; high accuracy through internal piston position feedback

Unpacked Weight: 9.100 kg

External pilot oil supply, internal pilot oil return
Spool valve
Pilot-operated
Linear with fine control range
Digital interface, IO-Link for I4.0
Maximum flow 4700 l/min
Size 10 … 35
Component series 4X
Maximum operating pressure 350 bar
Rated flow 60 … 1500 l/min

Data Sheet	Download Data Sheet
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual

Connection diagram	ISO 4401-05-05-0-05
Max. pressure	350
Max. flow	300
Spool symbol	Symbol V
Type of connection	Subplate mounting
Nominal flow	100
Size	10
Type of actuation	Electrical with integrated electronics
Number of ports	4
Number of switching positions	3
Supply voltage	24 VDC
Electrical connector	Connector 7-pole (6 + PE)
Electrical connection description	Connector 7-pole (6 + PE) according to EN 175201-804
Connectivity	Analog, command value 4 … 20 mA
Conformity description	CE – electromagnetic compatibility 2014/30/EU RoHS Directive 2011/65/EU REACH Regulation (EC) no. 1907/2006
Conformity	CE,RoHS
Conformity	CE
Hydraulic fluid	HL,HLP,HFC (Fuchs: Hydrotherm 46M, Renosafe 500; Petrofer: Ultra Safe 620; Houghton: Safe 620; Union: Carbide HP5046)
Seals	NBR
Productgroup ID	9,10,11,12,13,14
Connection diagram NFPA	NFPA T3.5.1 R2-2002 D05
Size_CETOP	D05
Weight	9.100
