DIRECTIONAL SPOOL VALVE 3WE6A7X/HG24N9K4/V

Manufacturer: Bosch Rexroth

Material #: R901259695

Model : 3WE6A7X/HG24N9K4/V

Destination

$666.50 USD

Availability: Backordered

Ships from CA

Add to Cart

Qty:
Delivered as early as August 13, 2026

DIRECTIONAL SPOOL VALVE 3WE6A7X/HG24N9K4/V

Size 6, symbol A, electrical, 24 V DC

Industrial hydraulic valve in the medium performance range. Reliable switch-over of the oil flow direction according to hydraulic symbol.

Unpacked Weight: 1.260 kg

Direct actuated
Spool valve
Maximum flow 60 l/min
Size 6
Maximum operating pressure 315 bar
Component series 7X

Data Sheet	Download Data Sheet
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual

Connection diagram	ISO 4401-03-02-0-05
Max. pressure	315
Max. flow	50
Spool symbol	Symbol A
Type of connection	Subplate mounting
Size	6
Type of actuation	with solenoid actuation
Number of ports	3
Number of switching positions	2
Supply voltage	24 VDC
Electrical connector	Connector 3-pole (2 + PE)
Electrical connection description	Connector 3-pole (2 + PE) according to EN 175301-803
Hydraulic fluid	HL,HLP,HLPD,HVLP,HVLPD,HETG,HEES,HEPG,HFDU,HFDR
Hydraulic fluid	HL,HLP,HLPD,HVLP,HVLPD,HETG,HEES,HEPG,HFDU,HFDR
Seals	FKM
Productgroup ID	9,10,11,12,13,14
Connection diagram NFPA	NFPA T3.5.1 R2-2002 D03
Size_CETOP	D03
Weight	1.260
