INTERNAL GEAR PUMP PGH3-2X/013RE07WU2

Manufacturer: Bosch Rexroth

Material #: R901244017

Model : PGH3-2X/013RE07WU2

Destination

$3,208.00 USD

Availability: Backordered

Ships from US

Add to Cart

Qty:
Delivered as early as January 1, 2027

$3,368.40 USD

Availability: Backordered

Ships from CA

Add to Cart

Qty:
Delivered as early as January 1, 2027

INTERNAL GEAR PUMP PGH3-2X/013RE07WU2

Internal gear pump, size 13, pressure 350 bar for industrial applications, open circuit

Suitable for variable-speed drive. Low noise and pulsation level. High efficiency thanks to gap compensation. Cast iron housing, no load cycle limitation. Can be combined flexibly with other Rexroth pumps.

Unpacked Weight: 7.44 kg

Cast iron housing
Internal gear pump with constant displacement
For industrial applications in open circuit
With NBR seals
Maximum operating pressure 350 bar
Frame size 2, 3
Size 5 … 16

Data Sheet	Download Data Sheet
3D CAD	Download 3D CAD
3D CAD	Download 3D CAD

Displacement type	constant
Size	13
Max. pressure	350
Max. flow	39.9
Shaft end	Cylindrical Ø 20 with fitting key, ISO 3019-2
Through-drive	with
Direction of rotation	clockwise rotation
Shaft end	Cylindrical Ø 20 mm with fitting key, ISO 3019-2
Fastening	2-hole mounting flange 82-2 according to ISO 3019-1
Hydraulic fluid	HLP,HFC
Seals	NBR
Fastening	2-hole mounting flange 82-2, ISO 3019-1
Speed min.	600
Productgroup ID	9,10,11,12,13,14
Speed max.	3000
Weight	7.44
