LOGIC COVER LFA50DBS2-7X/200

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LFA50DBS2-7X/200 (R901145429) is a sophisticated hydraulic control valve designed for precise pressure regulation in hydraulic systems. This model, specifically tailored for subplate mounting, offers manual pressure adjustment capabilities with the option to switch off the maximum pressure adjustment feature for enhanced control. Its construction adheres to ISO standards, ensuring compatibility with way cartridge valves and providing a reliable means of limiting pressure in conjunction with such valves. The LFA50DBS2-7X/200 boasts a hexagon pressure rating of up to 350 bar, capable of handling high-pressure applications with ease. It falls under the product group ID and features NBR seals suited for various hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, and HFC types. This valve operates as a pilot-controlled device available in seat or spool designs. The power section is integrated into a standardized receiving hole according to DIN ISO norms and is secured with a control cover. The pilot control valve can be either manually adjusted or electrically proportional and is integrated into or mounted on the control cover following DIN standards. In terms of functionality, this model offers both pressure relief and reducing functions without area difference at port B. For the pressure relief function, it operates as a seat valve where the effective pressure at port A is managed by the pilot oil supply orifice to ensure that the spool remains closed under spring force until the set pressure is reached. Conversely, in its role as a spool valve for pressure reducing functions, it allows free flow from port B to port A until reaching the set pressure where it then closes to reduce the outlet pressure. The versatility of Bosch Rexroth's LFA50DBS2-7X/200 makes it an essential component for applications requiring precise and reliable hydraulic pressure management.
