PRESSURE SWITCH HED 8 OP-2X/200K14KW

Manufacturer: Bosch Rexroth

Material #: R901108018

Model : HED 8 OP-2X/200K14KW

Destination

$535.10 USD

Availability: Backordered

Ships from CA

Add to Cart

Note: Sales tax, shipping, and applicable tariffs will be calculated at checkout.

Qty:
Delivered as early as October 13, 2026

PRESSURE SWITCH HED 8 OP-2X/200K14KW

200 bar, micro switch with NC contact/NO contact function, device connector DIN EN 175301-803 (large cubic connector)

Potential-free switching of currents from 1 mA to 2.0 A. Small hysteresis, depending on the set switching point. High repetition accuracy < 1% of the set pressure

Unpacked Weight: 0.86 kg

Piston type pressure switch
Micro switch with NC contact/NO contact function
Subplate mounting
Without mating connector, connector DIN EN 175301-803
With NBR seals
Rotary knob with scale
Component series 2X
UL recognized component, CCC-certified
Maximum operating pressure 630 bar
Pressure ratings 50, 100, 200, 350 and 630 bar

Data Sheet	Download Data Sheet
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual

Connection diagram	Subplate mounting
Max. pressure	200
Type of connection	Subplate mounting
Output signal	Micro switch with normally closed contact/NO contact function
Supply voltage	12...250 V AC/DC
Electrical connector	Connector 4-pole (3 + PE)
Electrical connection description	Connector 4-pole (3 + PE) according to EN 175301-803
Conformity description	CE – according to Low-Voltage Directive 2014/35/EU
Conformity	CE,CCC,UL,RoHS
Hydraulic fluid	HL,HLP,HLPD,HVLP,HVLPD
Seals	NBR
Productgroup ID	9,10,11,12,13,14
Weight	0.86
