R023620301

SWITCH 20 BG

Manufacturer: Bosch Rexroth

Material #: R023620301

Model : SWITCH 20 BG

Destination

$128.67 USD

Availability: Backordered

Ships from US

Add to Cart

Note: Sales tax, shipping, and applicable tariffs will be calculated at checkout.

Qty:
Delivered as early as November 6, 2026

SWITCH 20 BG

Unpacked Weight: 0.121 kg

Electrical accessories for linear axes	Mechanical switch
Permissible ambient temperature	-5 °C ... +85 °C
Switching function version	Single-pole changeover/(NC: C+NC, NO: C+NO)
B10d value	5x10⁶ (wet area); 10x10⁶ (dependent on current load (dry area))
Productgroup ID	17
Connection type	Screw connection, without line
Permissible ambient temperature (max)	+85
Compatible	SGK, SOK
Permissible ambient temperature (min)	-5
Switching frequency	3.3
Protection class	IP67
Load current	≤5
Max. permissible approach speed	1
Functional principle	mechanical, roller
Use	Limit switch
Function indicator	no
Weight	0.121

Technische Daten

Part number		R345304016	R347600305	R117500151	R117500162	R023620301
Functional principle		mechanical, roller
Operating voltage	V AC	250
Load current	A	≤ 5
Switching function		Single-pole changeover/(NC: C+NC, NO: C+NO)
Connection type		Screw connection, without line
Function indication		‒
Switching frequency	Hz	3.3
Maximum permissible starting speed	m/s	1
Permissible ambient temperature (min ... max)		-5 °C ... +85 °C
Protection type		IP67
B10d value		5x106 (wet range); 10x106 (depending on current load (dry area))

Mechanical switch without additional component

1)	R345304016
2)	R347600305

Mechanical switch with additional component

Certifications and approvals, housing
Certifications and approvals, switching element
