4WE 10 GA3X/CW110N9K4=CSA

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE 10 GA3X/CW110N9K4=CSA (R900716006) is a high-performance directional spool valve designed for controlling the start, stop, and direction of a flow in hydraulic systems. This particular model features a robust housing, one or two wet-pin electronic solenoids, a control spool with return springs, and manual override capabilities. The solenoids are responsible for moving the control spool from its rest position to the desired end position, thereby directing the flow between ports. The valve's design allows for precise operation with the force of the solenoid acting through a plunger on the control spool. When de-energized, the return springs ensure that the control spool returns to its original position. Additionally, this model includes a throttle insert option for increasing flow resistance in specific channels (P, A, B, or T), which is beneficial when operating conditions produce flows that exceed the valve's performance limit. This version of the directional valve does not have spring return at the control spool and hence does not maintain a defined basic position when de-energized unless it is equipped with detents. With detents in place, it can lock the control spool in position without continuous current application to the solenoids—enhancing energy efficiency. The Bosch Rexroth 4WE 10 GA3X/CW110N9K4=CSA valve is compatible with ISO porting patterns and features high-power solenoids suitable for both AC and DC applications. The solenoid coil can be rotated by 90 degrees and replaced without opening the pressure-tight chamber—an advantageous feature for maintenance purposes. Electrical connections can be made individually or through a central connection. An optional auxiliary operating device further enhances operational flexibility. This product is ideal for various hydraulic applications where reliable directional control is essential.
