AXIAL-PISTON PUMP A A10VSO 45 DRS /32R-VSB32U00E QDP1

Manufacturer: Bosch Rexroth

Material #: R902566714

Model : A A10VSO 45 DRS /32R-VSB32U00E *GOEU

Destination

$4,190.87 USD

Availability: Backordered

Ships from CA

Add to Cart

Qty:
Delivered as early as July 30, 2026

Source From Bosch Rexroth

Unavailable

AXIAL-PISTON PUMP A A10VSO 45 DRS /32R-VSB32U00E *QDP1*

A10VSO, variable displacement unit, open circuit, medium pressure, size: 45 cm³, pressure flow controller, with through drive

A10VSO is a variable pump with axial piston transmission in swash plate design for hydrostatic drives in the open circuit. The flow is proportional to the drive speed and the displacement. By adjusting the swash plate, the flow can be steplessly changed.

Unpacked Weight: 34.2 kg

Data Sheet	Download Data Sheet
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual
Manual	Download Manual

Version_1	Standard
Version_2	Standard
Product family	A10VSO
Product (axial piston unit)	A10VS
Type of actuation	Variable pump, open circuit
Size (displacement)	45
Control device	DR F controller X-T plugged 32/53
Series	Series 3, index 2
Direction of rotation	clockwise (w.view on shaft end)
Sealing material	FKM (standard)
Shaft end	Splined shaft
Mounting flange	ISO 3019-2 (metric), 4 hole
Working ports	B fla l metr, S fla l metr PCV
Through drive	Universal through drive
Connector for solenoids	Without
Rotational speed	1500
Working pressure	280
Max. displacement	45.0
Max. displacement setting	Fix
Min. displacement	0.0
Min. displacement setting	Fix
Max. flow	67.5
Min. flow	0.0
Internal drain line	No
Pressure differential FR	14.0
Classification society (external)	No
Test certificate	Without
Test certificate language code	Without
Paint/base coat	without
Paint/top coat	without
ATEX type of protection	without
Productgroup ID	9,10,11,12,13,14
Weight	34.2
