4WE 10 EB3X/CG205N9K4/V
Manufacturer: Bosch Rexroth
Material #: R900765533
Model : 4WE 10 EB3X/CG205N9K4/V
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE 10 EB3X/CG205N9K4/V (R900765533) is a high-performance directional spool valve designed for controlling the start, stop, and direction of fluid flow within a hydraulic system. This model features a robust housing, one or two wet-pin electronic solenoids, a control spool, and return springs that ensure reliable operation. The solenoids actuate the spool by pushing it from its rest position to the desired end position, enabling precise control of flow direction from ports P to A and B to T or vice versa.
The valve is equipped with a manual override for manual actuation in the absence of solenoid power. It also includes throttle inserts which can be used to increase flow resistance in specific channels (P, A, B, or T), enhancing performance under varying operating conditions. The model is designed without spring return at the control spool when de-energized for versions with symbols A, C, and D. Additionally, versions with detent (OF) are available for these symbols as well, which lock the control spool in place and allow energy-efficient operation by eliminating the need for continuous current application.
This particular valve has multiple spool positions and electronic solenoids without detent. It is important to note that pressure peaks in tank lines shared by multiple valves could cause unintended movements of the control spool if equipped with a detent; thus separate return lines or check valves are recommended.
The 4WE 10 EB3X/CG205N9K4/V valve features high-power solenoids and conforms to ISO porting patterns. Its AC solenoids have detachable coils that are rotatable by 90 degrees and can be replaced without opening the pressure-tight chamber. Electrical connections can be made individually or centrally, with an optional auxiliary operating device available for added flexibility in application.
Qty | Price | Savings |
---|---|---|
5+ | $0.00 USD | $0.00 USD |
This product is not available. CLICK HERE to create a support ticket for us to locate your part or a suitable replacement
