BALL GUIDE RAIL CARBON STEEL KSA-020-SNS-S-MA-AB

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160586132) is a high-precision ball guide rail designed for applications that demand superior accuracy and rigidity. This guide rail is part of the ball rail systems, which are known for their robust performance in various loading conditions. The model features a slimline width, standard height, and normal length (SNS format), making it a versatile component for linear motion requirements. It is constructed from carbon steel (CS), ensuring durability and strength in harsh environments. This particular model comes with a two-piece rail system that offers maximum rigidity in all load directions and has an impressive torque load capacity. It includes a cover strip made from corrosion-resistant spring steel according to DIN EN standards, which, along with screw-down plastic protective caps on end faces, provides additional protection against environmental factors. The guide rail's fastener type MA indicates that it can be bolted from above for secure installation. With an accuracy class of super precision (SP), the B.GUIDE RAIL CS ensures exact positioning and smooth operation in critical applications. The permissible ambient temperature range for this model extends from -10°C to +100°C, accommodating various working conditions. For longer or shorter lengths outside standard offerings, the manufacturer recommends calculating the required length using the formula L = nB * T ± mm. The profiled rail system comes with a mass of 2.9 kg/m, showcasing its robustness without being excessively heavy. It supports a maximum length (Lmax) of 1 meter and maintains a consistent pitch across its length for reliable guidance of runner blocks or other linear motion components. In summary, the Bosch Rexroth B.GUIDE RAIL CS is an advanced linear guide system designed to meet stringent precision requirements while withstanding challenging environments. Its construction and features make it suitable for applications that necessitate high rigidity and accurate linear movement.
