PRECISION MODULE PSK-090-NN-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth PRECISION MODULE PSK-090-NN-2 (R146540010) is a highly engineered linear motion system designed for dynamic and precise positioning tasks. This module is characterized by its robust construction and high-performance capabilities, suitable for a variety of automation applications. It features a dynamic load capacity for the guideway (Cgw) that ensures stable operation even under high dynamic loads. The module can handle maximum permissible dynamic torsional moments about the x-axis (Mx max), y-axis (My max), and z-axis (Mz max), allowing it to withstand complex loading conditions during operation. With its impressive maximum acceleration (amax) and maximum permissible linear speed (vmax), the PRECISION MODULE PSK-090-NN-2 is capable of rapid movements, making it ideal for applications requiring both speed and precision. The planar moments of inertia about the y-axis (ly) and z-axis (lz) contribute to its stability, ensuring accurate positioning even at high speeds or when subjected to external forces. The module's design accommodates a range of ambient temperatures, with specific performance metrics provided for mechanical systems and when paired with Rexroth servo motors. It maintains functionality within these temperature ranges without compromising performance or risking condensation due to temperature drops below the dew point. Bosch Rexroth has also considered the dynamic load capacities in various directions, with Fy max indicating the maximum dynamic load in the y-direction, Fz max in the z-direction, and Cfb for the fixed bearing capacity. These specifications are based on standardized testing according to DIN ISO norms over a 100,000 m travel distance, assuring users of consistent performance throughout its operational lifespan. Overall, the Bosch Rexroth PRECISION MODULE PSK-090-NN-2 is tailored to meet demanding automation needs where precision, speed, and reliability are paramount. Its comprehensive design parameters provide flexibility in application while maintaining stringent performance standards expected from Bosch Rexroth products.
