SOLID SHAFT WV-5H7-X46
Manufacturer: Bosch Rexroth
Material #: R100000531
Model : SOLID SHAFT WV-5H7-X46
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SOLID SHAFT (R100000531) is a precision-engineered component designed for use in applications where corrosion resistance and cleanliness are paramount. This solid shaft is crafted from corrosion-resistant steel, ensuring its suitability for environments such as the food industry, semiconductor production, and medical equipment manufacturing. The shaft adheres to ISO standards with a diameter tolerance classified under grade H, indicating high precision in its construction.
The product features a millcut length L and can be provided in various lengths to meet specific requirements, with the maximum usable length Lmax being subject to other tolerances upon request. For applications requiring lengths greater than Lmax, sections of the shaft can be combined seamlessly, allowing linear bushings to roll smoothly over joints without interruption.
Manufactured from XCrMoV 15 – a steel known for its superior resistance to lactic acid compared to X46 Cr13 – this model ensures durability and longevity even under harsh conditions. The material's hardness is maintained at a minimum of 58 HRC, with surface roughness RA maintained at 0.3 µm or less, ensuring minimal friction and wear during operation.
Precision is further exemplified by the strict adherence to cylindricity and roundness tolerances as well as straightness tolerance. The straightness of the shaft is measured based on ISO standards, with the smallest possible deviation set at 0.3 mm for lengths under 1 meter.
In summary, the Bosch Rexroth SOLID SHAFT is an optimal choice for demanding applications requiring high levels of hygiene and resistance to corrosive substances. Its robust construction and precise manufacturing standards make it an essential component for any system that demands reliability and exacting performance.
This product is not available. CLICK HERE to create a support ticket for us to locate your part or a suitable replacement
Dimensional accuracy and tolerance zones
The diameters of the precision steel shafts come in h6 and h7 tolerance zones. The adjacent table shows information on dimensional accuracy. The diameter tolerance of annealed shaft cross-sections vary slightly from the specified tolerance zone.
|
Ød |
mm |
4 | 5 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | |||||||||||||||
|
Tolerance grade 1) |
h6 | h7 | h6 | h7 | h6 | h7 | h6 | h7 | h6 | h7 | h6 | h7 | h6 | h7 | h6 | h7 | h6 | h7 | h6 | h7 | h6 | h7 | h6 | h7 | h6 | h7 | h6 | h7 | h6 | h7 | |
|
Diameter tolerance |
µm |
0 - 8 |
0 - 12 |
0 - 8 |
0 - 12 |
0 - 8 |
0 - 12 |
0 - 9 |
0 - 15 |
0 - 9 |
0 - 15 |
0 - 11 |
0 - 18 |
0 - 11 |
0 - 18 |
0 - 11 |
0 - 18 |
0 - 13 |
0 - 21 |
0 - 13 |
0 - 21 |
0 - 13 |
0 - 21 |
0 - 16 |
0 - 25 |
0 - 16 |
0 - 25 |
0 - 19 |
0 - 30 |
0 - 19 |
0 - 30 |
|
t1 |
µm |
4 | 5 | 4 | 5 | 4 | 5 | 4 | 6 | 4 | 6 | 5 | 8 | 5 | 8 | 5 | 8 | 6 | 9 | 6 | 9 | 6 | 9 | 7 | 11 | 7 | 11 | 8 | 13 | 8 | 13 |
|
t2 2) |
µm |
5 | 8 | 5 | 8 | 5 | 8 | 6 | 9 | 6 | 9 | 8 | 11 | 8 | 11 | 8 | 11 | 9 | 13 | 9 | 13 | 9 | 13 | 11 | 16 | 11 | 16 | 13 | 19 | 13 | 19 |
|
t3 3) |
µm/m |
150 | 120 | 100 | |||||||||||||||||||||||||||
|
Ra |
µm |
0.32 | |||||||||||||||||||||||||||||
| 1) | Other tolerances upon request |
| 2) | Measurements if differences in diameter |
| 3) | The smallest possible value is 40 µm for lengths under 1 m. Straightness is measured based on ISO 13012. |
Measurement of straightness based on ISO 13012
The measuring points are evenly distributed between the support points and the shaft sections protruding past them. More supports are used accordingly for long, thin shafts. Straightness is half of the gauge measurement when turning the shaft 360°.
Measurement of roundness
The drawing shows the roundness of a raw shaft compared to a precision steel shaft.
a) Raw shaft
b) Precision shaft
Shaft hardness
The outer zone of the shaft is induction-hardened. Depending on the shaft diameter, the depth of hardness ranges from 0.4 to 2.4 mm. Linear and transverse surface hardness and depth of hardness are highly consistent. This ensures high dimensional consistency and long service life. The adjacent figure shows the cross-section and longitudinal section of a hardened and polished precision steel shaft. The hardened surface zone is made visible by caustic etching.
Technische Daten
|
Ød |
mm |
4 | 5 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 25 | 30 | 40 | 50 | 60 | 80 |
|
L 1) |
mm |
75 | ||||||||||||||
|
Mill-cut length |
mm |
3600 | 6100 | |||||||||||||
|
Lmax 2) |
mm |
3600 | 6100 | |||||||||||||
|
Hardness |
min. 54 HRC | |||||||||||||||
|
Material no. |
1.4034 | |||||||||||||||
|
Depth of hardness (min.) |
mm |
0.4 | 0.6 | 0.9 | 1.5 | 2.2 | ||||||||||
|
m |
kg/m |
0.1 | 0.15 | 0.22 | 0.39 | 0.61 | 0.88 | 1.2 | 1.57 | 2.45 | 3.83 | 5.51 | 9.8 | 15.32 | 22.05 | 39.21 |
| 1) | Regarding geometry and hardness |
| 2) | Sections are combined for longer overall lengths. Linear bushings can simply be rolled over joints. |
Legend
|
Symbol |
Description |
Unit |
|
Ød |
Shaft diameters |
mm |
|
L |
Length |
mm |
|
Lmax |
Maximum length |
mm |
|
m |
Mass |
kg/m |
|
t1 |
Roundness tolerance |
μm |
|
t2 |
Cylindricity |
μm |
|
t3 |
Straightness |
μm/m |
|
Ra |
Surface roughness |
μm |
Technical data
Shaft machining
Chamfering
When used as round guides for Linear Bushings, the ends of steel shafts must be chamfered so the ball retainers/wiper seals are not damaged when the Linear Bushings are pressed onto the shafts. The figure and table show the chamfering dimensions. Linear bushings with wiper seals cannot be pressed over sharp edges on the shaft (e.g., retaining ring grooves) since the sealing lips will be damaged.
|
Shaft diameters |
mm |
3 |
4 |
5 |
8 |
10 |
12 |
14 |
16 |
20 |
25 |
25 |
30 |
40 |
50 |
60 |
80 |
|
Length of chamfers L1 |
mm |
1 |
1,5 |
1,5 |
1,5 |
1,5 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
3 |
3 |
3 |
3 |
Processing
Hardened and polished steel shafts are available in mill-cut lengths. These can be cut to size and machined to include:
Spigots Female and male threads Counterbores Radial and axial holes Grooves Other machining
Unmachined, cut-to-size shafts come chamfered for accident prevention unless ordered otherwise.
Annealing machined sections
Annealing may be necessary when machining shafts due to the hardened outer zone (minor change in size possible).
Length tolerance for cut-to-size shafts
|
Shaft length |
Tolerance (mm) |
|
< 400 |
±0,5 |
|
≤ 400 ‒ 1000 |
±0,8 |
|
≤ 1000 ‒ 2000 |
±1,2 |
|
≤ 2000 ‒ 4000 |
±2,0 |
|
≤ 4000 ‒ 6000 |
±3,0 |
|
≤ 6000 ‒ 8000 |
±3,5 |
Steel shafts with smaller length tolerances are also available at additional cost.
Concentric and axial spigot runout
A review in accordance with a specified principle will be performed upon request. Values xxx < 0.02 on request.
a) about 50 mm
Life expectancy calculation
Interconnected shafts – plug-and-socket connection
We also provide interconnectable steel shafts when more than the mill-cut length is needed. One shaft then comes with a spigot-and-recess arrangement, the next with a matching recess (see figure). The interconnected shaft must be supported throughout or at intervals, though generally at the joins (see Section "Shaft support rails"). The shafts must be under axial tension when fastening the shaft support rails so no gaps form at the joins. Linear bushings can simply be rolled over joints.
