LIFT TRANSFER UNIT HQ 2/C-H

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LIFT TRANSFER UNIT HQ 2/C-H (3842999002) is a sophisticated piece of equipment designed for the efficient transfer of workpiece pallets between longitudinal and transverse sections within an automated system. It is engineered to handle high total weights, supporting up to kgcm on the smallest side of the workpiece pallet and capable of dealing with a total weight of up to kg. This unit exhibits a flat construction, which not only enables multi-level system layouts but also ensures a compact footprint. The lift transfer unit operates with a synchronized lifting movement facilitated by four block cylinders, guaranteeing uniform and parallel lifting. It employs a flat top chain as its conveyor medium, ensuring smooth and reliable movement of goods. It is compatible with mounting on either an ST section with a profile width of mm or an ST H section with the same profile width, demonstrating its versatility in integration with existing systems. This model can be utilized alongside various other conveyors such as WT , WT F, WT H, and WT FH for expanded functionality. Height-adjustable lateral guides included in the design can act either as fixed stops for exporting or as lateral guides during workpiece pallet transitions. The unit also features reversible operation capabilities but does not support accumulation operation. Moreover, it includes numerous accessories like switch holders for mm sensors for position inquiry, assembly kits for electrical position inquiry, and lateral guide kits accommodating different track widths. The Bosch Rexroth LIFT TRANSFER UNIT HQ 2/C-H comes fully assembled with kits for lateral guides included in delivery, ensuring ease of installation and setup. Designed to be energy-efficient under the Rexroth EE classification, this lift transfer unit is an ideal solution for seamless material handling in diverse automated environments where precise control and heavy-duty lifting are required.
