LIFT TRANSFER UNIT HQ1/U
Manufacturer: Bosch Rexroth
Material #: 3842998010
Model : LIFT TRANSFER UNIT HQ 1/U
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LIFT TRANSFER UNIT HQ1/U (3842998010) is an advanced lift transverse unit designed for the efficient handling and transportation of workpiece pallets within automated systems. This model boasts an extremely compact construction, with a gear motor located at the bottom to save space, making it ideal for tight areas. It utilizes a toothed belt as its conveyor medium, which includes a mesh top suitable for Electrostatic Discharge (ESD) protected areas, ensuring safe operation in sensitive environments.
The unit features a lift cylinder that provides the necessary vertical motion to transfer workpiece pallets between different conveyor sections. It is engineered to facilitate reversible operations while not permitting accumulation operation, aligning with energy efficiency standards set by Rexroth EE. The HQ1/U can be configured for top, center, or top-center-bottom lift positions depending on specific application requirements.
Connection to power sources can be customized with either a cable plug AT S or a terminal box AT K, and while special models can be requested to meet unique needs, the standard product comes fully assembled. This includes protective housing and fastening materials required for attachment to an ST section profile.
For optimal performance, additional accessories such as dampers, switch brackets, and sensors might be necessary depending on installation circumstances. Moreover, two throttle non-return valves M are required for air intake throttling. The unit's design allows it to handle varying weights of workpiece pallets efficiently while operating within prescribed pneumatic pressure ranges.
In summary, the Bosch Rexroth LIFT TRANSFER UNIT HQ1/U is a versatile and compact solution designed for seamless integration into automated material handling systems where space optimization and ESD compatibility are essential.
