Manufacturer: Bosch Rexroth

Material #: 0811403112

Model : 3FREX6B-1X/7,5L2G24-25N9Z4MM

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 3FREX6B-1X/75L2G24-25N9Z4MM (0811403112) is a sophisticated proportional flow control valve designed for precise fluid handling in hydraulic systems. This direct-operated valve falls within the NG6 and NG10 size categories, ensuring compatibility with standard porting patterns as per ISO 4401 for subplate mounting. Its operation is controlled by a proportional solenoid, which allows for fine-tuning of the flow rate, with an impressively low hysteresis of less than 5%, ensuring consistent and accurate control of the hydraulic fluid. This particular model can be adjusted through changes in the solenoid current, enabling users to manage flow rates effectively. The valve's versatility is highlighted by its dual function; it can operate as a 2-way flow control valve when configured with the "NO" (normally open) symbol and as either a 2-way or 3-way flow control valve when using the "NC" (normally closed) symbol. In its 3-way configuration, residual flow is directed via port P, while in a 2-way setup, ports A to B are operational with ports P and T closed. The Bosch Rexroth proportional flow control valves are designed without position control but come equipped with various amplifier electronics options to cater to different system requirements. These valves are integral components for applications requiring precise fluid management and are particularly suitable where system stability and response sensitivity are critical. Their robust design and flexible configuration options make them ideal for use in advanced hydraulic circuits that demand high levels of reliability and performance.

This product is not available. CLICK HERE to create a support ticket for us to locate your part or a suitable replacement

This product is eligible for factory repair.
